• Quick Detail:

  • Type: Wooden pattern or DIY • Function: Fireproof, Heat Insulation, Moisture-Proof, Mould-Proof, Sound-Absorbing, Waterproof • Feature: Artistic Ceilings, Honeycomb Ceilings, Integrated Ceilings, Perforated Ceilings • Ceiling Tile Shape: Strip • Material: PVC Resin, calcium carbonate • PVC content: 50%, 60%, 73%, 77%, 87% • Weight: 1.5-4 kg/sqm • Surface Process: Printing, Hot stamping, Laminated • Quality Guarantee: 25 years • Usage: Ceiling panel and Wall panel

• Description of Recyclable Plastic Wall Covering Panels :

  1. Self-fire extinguishing, non-flammable. 2. DIY is all right 3. It is impenetrable by insects or termites, and won’t rot or rust. 4. Resistance to weather/ special chemicals; Waterproof / Washable. 5. The excellent rigid and superior impacted surface is without any peeling. 6. Natural wood grain: showing authentic wood structure and artistic sense. 7. Easy to be cut, drilled, nailed, sawed, and riveted. . 8. Free of maintenance. No cracking, swelling and deforming; Free maintenance and keeping,easy cleaning; cost saving for the maintenance and keeping.

• Applications:

In recent years PVC has become an advantageous alternative than traditional materials for decorating and rearranging of interior spaces in the various environments such as residences, hotels, restaurants. industrial units, individual offices, bathrooms, kitchens, laundries.

• Specifications of Recyclable Plastic Wall Covering Panels :

Product name	Customized Size Exterior Wall Panel Recyclable Plastic Wall Covering Panels
Main material	PVC (50%, 60%, 73%, 77%, 87% or as your request), calcium carbonate and other chemicals
Usual specification	Length: customized size, such as 2.95m, 3m, 3.8m, 5.6m, 5.8m, 5.95m Width: 5cm to 40cm or customized Thickness: 5mm to 10mm or customized
Surface treatment	Oil print, hot stamping foil, thermal transfer print, laminated and so on as your pattern and color
Surface effect	Bright/glossy, high glossy, matt, gleam, roller coating and so on
Production quality	Light of weight, powerful strength, high intensity, heat insulation, flame resistant, corrode resistant, age resistant, no aspiration, easy cleaning, easy installing and so on
Producing scale	With more than 60 PVC production lines and 100 kinds of moulds
Certificate	ISO9001:2000, Soncap, Intertek, SGS
Application	Hotels, commercial buildings, hospital, schools, home kitchen, bathroom, indoor decoration and so on
Sample	Free with International Express Delivery



• Test Report



Report No.	V03-1300143				Specification	200×10mm
Product	PVC Wall Panel				Standard	BS EN 13501-1:2007
Test Items		Measure Unit		Technical Requirement		Test Results	Individual Judgment
Fire growth rate index (Figra)		W/s	C		≤250	105	Compliant
Lateral flame spread( LFS)		m			<edge of specimen	Yes	Compliant
Total heat release within 600 s(THR 600s)		MJ			≤15	11.5	Compliant
Flame spread (Fs)	Surface	mm			≤150	30	Compliant
	Edge					33	Compliant
Smoke growth rate (SMOGRA)		m2/s2	S2		≤180	192	S3 Compliant
Total smoke production within 600 s(THR 600s)		m2			≤200	666
Flaming droplests/particles		------	d0		No flaming droplets/particles occur within 600s	Yes	Compliant
Ignition of the filter paper		------			No ignition of the filter paper	Yes	Compliant
Conclusion		The combustion performance of sample is satisfied BS EN 13501-1:2007 about grade C-s3,d0.
